Natural gas, pipes and fittings for gas plants

Natural gas

Raccorderie Metalliche
and gas transportation

Natural and LPG plants ask for pipes and fittings which are highly rated in terms of quality and safety as well. Raccoderie Metalliche made an entire range fitted with a unique O-Ring and marking: inoxPRES GAS and aesPRES GAS, respectively in stainless steel and copper.

Please accept preferences, statistics, marketing cookies to see this content

inoxPRES GAS

It is the Pressfitting pipe and fittings range in bonded CrNiMo 1.4404 (AISI 316L) steel, Ø15 to Ø108 mm.

Highly resistant to corrosion, it protects the gas quality inside. The fittings are fitted with an NBR/HNBR O-Ring. The compound was mainly developed for such an application and is yellow-dyed. The marking on each single joint is different and it is added the yellow RM GAS logo. Every fitting is pre-marked and pre-fitted with the GAS O-Ring as to ease and make any installation more rapid.

Read More

aesPRES GAS

In DHP 99.9 (CW024A) copper and CuSn5Zn5Pb2 (CC449K) bronze, it is the pressfitting range, from Ø12 to Ø54 mm offered by Raccorderie Metalliche.

Copper is a noble material well-known for its high resistance to corrosion and with a long-lasting tradition as for use for natural gas. aesPRES fittings are fitted with an NBR/HNBR O-Ring. The compound was mainly developed for such an application and is yellow-dyed. The marking on each single joint is different and it is added the yellow RM GAS logo. Every joint is pre-marked and pre-fitted with the GAS O-Ring as to ease and make any installation more rapid.

Read More

inoxPRES GAS and aesPRES GAS

Certified quality fittings.

Raccorderie Metalliche offers an easy, rapid and safety solution certified by the most important European bodies. The inoxPRES GAS fitting and pipe range is certified, Ø15 to Ø108 mm at PN5/GT1 in a temperature range -20/+70° C. aesPRES GAS fittings are certified, Ø15 to Ø54 mm at PN5/GT1 in a temperature range -20/+70° C. The M-shaped optimised profile and the patented Raccorderie Metalliche lenticular O-Ring provide for safety and duration in time.
