aesPRES UNIKO Gas

Press-fitting systems
in copper and brass/bronze for gas

aesPRES UNIKO GAS is the press-fitting system by Raccorderie Metalliche, developed for all applications involving methane gas, LPG, and hydrogen. It is distinguished by its marking and yellow O-Ring.

The material of
aesPRES UNIKO GAS

Copper Cu-DHP 99.9 /Brass CuZn21Si3P – CW724R /Bronze CuSn5Zn5Pb2 – CC499K.

The fittings are made from lead-free ecological brass and high-quality DHP copper, available in sizes from 12 to 54 mm. It is precisely with this material that a direct comparison between Pressfitting and traditional methods, such as brazing, becomes evident, highlighting all the advantages of the Raccorderie Metalliche product. The fittings are equipped with a patented 'UNIKO profile' toroidal chamber. Users of profile V and profile M can choose our new UNIKO profile offering without investing in new equipment or developing new skills, as it can be pressed with both V and M profiles. The fittings are equipped with a toroidal chamber in the 'Uniko profile', optimised based on Raccorderie Metalliche's experience, within which an O-Ring developed by Raccorderie Metalliche is directly mounted at the factory, resulting from a patented innovation. The aesPRES UNIKO GAS range of fittings is certified by the most respected international bodies. Among the certifications achieved, some are designated for applications such as drinking water, heating and cooling, both open and closed water circuits, and natural gas systems.

Be different be UNIKO

The UNIKO profile range offers the major advantage of being pressable with both M- and V-profile. This represents a significant patented innovation, certified by leading certification bodies, available for both water and gas. Users of both V and M series can opt for our new UNIKO proposal without the need to invest in new equipment or acquire new skills.

Why chose
aesPRES UNIKO GAS

The lenticular RM O-Ring enhances installation safety and enables faster fitting assembly.
A provider offering immediate availability with a significant stock for both civil and industrial sectors, boasting its own warehouse exceeding 14,000 square metres.
A product line developed for GAS applications, where each fitting is already equipped with a dedicated O-Ring.
An affordable solution in terms of price and service.

Where to use
aesPRES UNIKO GAS

We develop products and services aimed at addressing the most comprehensive installation issues effectively, focusing on quality, safety, and speed.

Copper is strongly linked to both domestic and industrial natural gas systems. The aesPRES UNIKO GAS range of fittings not only offers quality and reliability but also combines the ease of installation with the advantages of the Pressfitting system. The yellow O-Ring operates over a temperature range of -20 to +70°C and withstands a maximum pressure of 5 bar PN5/GT1, ensuring quality and safety.
