Raccorderie Metalliche and process water plants

Process water plays a leading if not strategic role in the industry: feeding water to heaters, cooling water to heat exchangers and motors, dilution of chemical products. As to provide for quality process water, a more or less complex treatment plant is required. Raccorderie Metalliche developed and certified their own Pressfitting system, in the two materials suitable for such a delicate application: stainless steel and cupronickel.

inoxPRES

It is the Pressfitting pipe and fitting range in bonded CrNiMo 1.4404 (AISI 316L) steel, Ø15 to Ø168 mm.
Raccorderie Metalliche developed its own bonded CrNiMo 1.4404 (AISI 316L) steel products, Ø15 to Ø168 mm. As to supply designers and installers the best possible solution, inoxPRES fittings can be used with 4 different ranges of stainless steel pipes:

complete range in 1.4404 (AISI 316L) raw steel, available Ø15 to Ø168 mm
complete range in 1.4404 (AISI 316L)annealed steel, available Ø15 to Ø108 mm
complete range in 1.4301 (AISI 304) steel, available Ø15 to Ø108 mm
complete range in 1.4301 (AISI 304) steel, reduced thickness, available Ø15 to Ø108 mm
complete range in 1.4521 (AISI 444) steel, available Ø15 to Ø54 mm

marinePRES

The pressfitting fittings and pipes, Ø15 to Ø108 mm by Raccorderie Metalliche in copper/nickel 90/10 CuNi10Fe1.6Mn alloy.

The marinePRES alloy is the best solution when the material intrinsic corrosion-proof features are required to assemble the plant. The use of marinePRES by Raccorderie Metalliche is suitable in general for applications in saline and corrosive media, as in time it proved to be extremely reliable. The system is suitable for plants with no drier. All marinePRES joints are fitted with a green O-Ring in FKM, compatible with Class 1 and 5 plants (ISO 8573-1/2001) and PN16 approved.
