Raccorderie Metalliche and cooling plants

Raccorderie Metalliche paid the due attention to cooling plant applications, developing its Pressfitting product in 4 different materials to provide installers and designers the best possible solutions to any requirement. Open or closed loop, in domestic or aggressive environments, as in case of some industrial processes, the Pressfitting system by Raccorderie Metalliche always provides for the most suitable solution.

Please accept preferences, statistics, marketing cookies to see this content

Raccorderie Metalliche and cooling plants

steelPRES

It is the range of unbonded steel Pressfitting pipes and fittings available from Ø12 to Ø108 mm. Fittings are made in E195 (n. 1.0034) and galvanised.

For closed loop heating plants, a single range of products, externally galvanized in E220 (n. 1.0215). The pipes are longitudinally welded, bordered and calibrated. steelPRES by Raccorderie Metalliche matched with an externally galvanized pipe is rightfully used in closed loops, civil and industrial heating plants. The pipes covered in polypropylene is used in case the temperature range difference between the plant and the surrounding environment leads to condensation build-up. It is then wise to use a pipe with a polypropylene layer to protect the metal. A further protection consists of covering of the fittings with a butyl bandage. Raccorderie Metalliche as to comply with the requirement to thermally insulate the plants, developed isoPRES that is a new range of customized insulating materials for the pressfitting and available from Ø15 to Ø54 mm. steelPRES fittings are pre-fitted EPDM O-Rings, a compound providing for the best possible performances: PM16 maximum pressure, temperature ranging between -20/+120° C and quality in time. The affordable price and the certified product quality by many international institutions make steelPRES the best possible product solution for a similar application.

Read More

inoxPRES

The best proposal matching features of stainless steel and benefits of the Pressfitting system.

Raccorderie Metalliche developed its own bonded CrNiMo 1.4404 (AISI 316L) steel products, Ø15 to Ø168 mm. As to supply designers and installers the best possible solution, inoxPRES fittings can be used with 5 different ranges of stainless steel pipes:

complete range in 1.4404 (AISI 316L) raw steel, available Ø15 to Ø168 mm
complete range in 1.4404 (AISI 316L)annealed steel, available Ø15 to Ø108 mm
complete range in 1.4521 (AISI 444) steel, available Ø15 to Ø54 mm
complete range in 1.4301 (AISI 304) steel, available Ø15 to Ø108 mm
complete range in 1.4301 (AISI 304) steel, reduced thickness, available Ø15 to Ø108 mm

The pipes are longitudinally welded, bordered and calibrated. Stainless steel high resistance to corrosion makes inoxPRES system by Raccorderie Metalliche the most suitable solution for thermal solar plants and circuits. At the civil and industrial level as well where processes and processing can lead to aggressive and corrosive environments, such a material turns out to be the most suitable solution.
All inoxPRES fittings are pre-fitted EPDM O-Ring, developed to be used providing for the highest possible performances: maximum pressure PN16, temperature ranges -20/+220° C and quality in time.
The 22 issued certifications from the most important certification bodies prove the high quality of inoxPRES by Raccorderie Metalliche, offering designers and installers an easy-to-use, reliable and safe solution in case of the most difficult and complex applications as well.

Read More

aesPRES

In DHP 99.9 (CW024A) copper and CuSn5Zn5Pb2 (CC449K) bronze, it is the pressfitting range, from Ø15 to Ø54 mm offered by Raccorderie Metalliche.

Copper is a noble material well-known for its high resistance to corrosion and duration in time. aesPRES joints by Raccorderie Metalliche are fitted with an EPDM O-ring, underwent and passed tests for the most important European certifications. The certified pressure accounts for PN16 and the O-ring compound exhibits an operating temperature -20/+120° C.

Read More

marinePRES

The range of pressfitting pipes and fittings, Ø15 to Ø108 mm by Raccorderie Metalliche in copper/nickel 90/10 CuNi10Fe1.6Mn alloy.

The marinePRES product range is suitable for any heating plants and circuits, open and close loops and it represents the best possible solution when the material intrinsic corrosion-proof features are required to assemble the plant. The use of marinePRES by Raccorderie Metalliche is suitable in general for applications in saline and corrosive media, as in time it proved to be extremely reliable. All marinePRES fittings are pre-fitted with a green O-Ring in FKM, providing for an operating use range from -20/+220°C and a maximum pressure accounting for 16bar. marinePRES offers a solution suitable to the most aggressive applications with the highest quality and safety standards.
